6k 8k 4x8 4x10 Decorative Stainless Steel Wall Panels 201 304 316 Mirror PVD Color Coated

Asia Metal Service Company Limited
Contact Now

6k 8k 4x8 4x10 Decorative Stainless Steel Wall Panels 201 304 316 Mirror PVD Color Coated

  • 1
  • 2
  • 3

Brand Name : ASIA METAL

Model Number : 201 304 316

Certification : ISO9001

Place of Origin : Guangdong China

MOQ : 1 Ton/Sheet

Price : $1/Tons 1-100 Tons

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 1000000 Tons Per Month

Delivery Time : 15-21 days

Packaging Details : Standard Sea-worthy Packing

Product Name : PVD Color Coated Stainless Steel Sheet

Material : Stainless Steel

Type : Sheet

Thickness : 0.3-3mm

Surface : Mirror+PVD

Width : 1000mm/1219mm/1240mm/1250mm

Edge : Mill Edge Slit Edge

Price Term : CIF CFR FOB EX-WORK

Payment Term : 30%T/T Advance + 70% Balance

Color : Customized

Sample : Provide

Contact Now

What is Stainless Steel ?
Stainless steel contains chromium which provides the properties of corrosion resistance at high temperatures. Stainless steel can withstand corrosive or chemical environments due to its smooth surface. Stainless steel products are safe for long-term use with excellent resistance of corrosion fatigue.

WHAT IS PVD TECHNOLOGY ?


PVD, Physical Vapor Deposition, is a process to produce a metal vapor that can be deposited on electrically conductive materials as a thin highly adhered pure metal or alloy coating.

PVD Product Advantage

ASIA METAL is equipped with high temperature vacuum furnace, adopting the world first-class PVD technology, which makes the color coating strongly attached to stainless steel surface, color is even and stable.

All colors can be combined with Mirror finish, Hairline finish, Embossed finish, Vibration finish and Etching finish, etc.

PVD Product Application

PVD Color Coating stainless steel sheets are widely used in architectural and decorative applications, such as hotel and restaurant decoration, wall panel, coping and trim, advertising board, also artistic objects.

Surface Finish Definition Application
2B Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface. With bright and smooth surface ,easy for further grinding to obtain brighter surface ,suitable for medical instruments ,milk containers ,tableware and so on.
BA Bright heat treatment after cold rolling. Structual members .etc.kitchen utensil ,cutlery ,eleltric applicances ,medical instruments ,building decorations ,etc.
NO.3/NO.4 Polished with No.150-240 abrasives. Milky food processing equipment , medicalinstruments ,building decorations.
HL Finshed by polishing with abrasives of suitable grain size to obtain continuous streaks. Building decorations ,such as elevators ,escalators ,door etc.
6K/8K A mirror-like reflective surface ,which is obtained by polishing with successively finer abrasives and buffing extensively with all gritlines are removed. Buliding entrances,bulkding column casting ,elevator's wall doors ,counters,sculptures etc.

Product Name
Mirror PVD Color stainless steel sheet
Type
Sheet
Grade
201
Thickness(mm)
0.3-3mm
Width(mm)
Main Demension
Other Demension
1000
1219
1240
1250
1500
Customized
Length(mm)
Max 6000mm & Customized
Surface
Mirror + PVD Color Coating
Color
Customized
Packing way
PVC+ waterproof paper + strong sea-worthy wooden package
Remarks
1. Special dimensions are accepted on request.
2. Customized specific cut-to-length, laser-cut, bending are acceptable.
Application
1. Building exterior walls
2. Building ceiling
3. Various stainless steel decorations
Chemical composition and mechanical properties of stainless steel coils
Grade Chemical Composition (%) Mechanieal Performece
C Si Mn P S Ni Cr Mo Hardness
201 ≤0.15 ≤1.00 5.5/7.5 ≤0.060 ≤0.030 3.5/5.5 16.0/18.0 - HB≤241,HRB≤100, HV≤240
304 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 8.0/11.0 18.00/20.00 - HB≤187,HRB≤90,HV≤200
316 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.00/14.00 16.0/18.0 2.00/3.00 HB≤187, HRB≤90 HV≤200
316L ≤0.03 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.00/14.00 16.0/18.0 2.00/3.00 HB≤187, HRB≤90 HV≤200
410 ≤0.15 ≤1.00 ≤1.25 ≤0.060 ≤0.030 ≤0.060 11.5/13.5 - HB≤183, HRB≤88 HV≤200
430 ≤0.12 ≤1.00 ≤1.25 ≤0.040 ≤0.03 - 16.00/18.00 - HB≤183, HRB≤88 HV≤200
